Safety: PVB heat-insulating interlayer film and composite glass layer have a strong adhesive strength, in the case of external impact, can prevent the impact of material penetration, even if the glass is broken, can still be attached to the glass fragments in the interlayer, will not fall off the four scattered injuries.
Energy Saving: PVB interlayer made of architectural, automotive laminated glass can effectively block infrared rays, have good thermal insulation performance, and high energy efficiency; the product has a high visible light transmittance, through the nano-insulating medium and the production process of reasonable adjustment of the visible light transmittance of the film as well as the adjustment of the coefficient of thermal insulation.
Anti-theft: PVB made of laminated glass is very tough, even if the burglars will break the glass, due to the intermediate layer with the glass firmly adhered together, but still maintains the integrity, so that the burglars can not enter the room.
Sound Insulation: As PVB film has the function of sound wave blocking, PVB laminated glass can effectively inhibit the spread of noise, especially in airports, stations, downtown, and road buildings on both sides of the installation of laminated glass, the sound insulation effect is very obvious.
| Items | Technical Indicators |
| Color | The light blue |
| Thickness | 0.38mm, 0.45mm, 0.76mm, 1.14mm, 1.52mm |
| Width (mm) |
700-3300mm （Can be customized according to requirements） |
| Minimum Length (m) | 150 |
| Visible Light Transmittance(%) | 30-85 |
| Infrared Group Of Heat Rate(%) | 80-99 |
| Haze(%) | ≤0.60 |
| Volatile Matter Content(%) | ≤0.55 |
| Tensile Strength(Mpa) | ≥20 |
| Bonding Strength(Mpa) | ≥8.0 |
| Wet And Heat Resistance | 70±2℃, Relative humidity,91-99%,48h no change |
| Heat Resistant Performance | 70±2℃, 48h no change |
| Cold Resistant | -55±2℃, 48h no change |
| Light Resistance | 750W Iluminant 100h Light transmittance by 2% |
